| Specifications | GS1000W | GS2000W | GS2500W | GS3000W | |
| Model Parameters | 1000W | 2000W | 2500W | 3000W | |
| AC Input | Nominal Power | 1000W | 2000W | 2500W | 3000W |
| Input Voltage Waveform | Sinusoidal (utility or generator) | ||||
| Nominal input Voltage | 120/230VAC | ||||
| Low Line Disconnect | 85Vac±4%(Normal) or 80Vac±4% (Wide) for 120V / 184Vac±4%(Normal) or 135Vac±4%(Wide) for 230V | ||||
| High Line Disconnect | 136Vac±4%(Normal) or 140Vac±4%(Wide) for 120V / 263Vac±4%(Normal) or 263Vac±4%(Wide) for 230V | ||||
| Max AC input Voltage | 120V for Max150V, 230V for Max270V | ||||
| Frequency | 50Hz:41-54Hz, 60Hz:51-64Hz | ||||
| AC Output | Output Voltage Waveform | Sine wave | |||
| Power Factor | 0.9~1.0 | ||||
| Nominal Output Voltage (V) | LV:120Vac ±10%rms, HV:230Vac ±10%rms | ||||
| Nominal Output Frequency (Hz) | 50Hz ± 0.3Hz, 50Hz ± 0.3Hz | ||||
| Solar Charger | Rated Charge Current | 40A | 60A | ||
| PV Input Voltage range | 15VDC-40VDC for 12VDC, 30VDC-55VDC for 24VDC, 60-110VDC for 48V | ||||
| Max.PV open circuit array voltage | 12V for 40Vdc, 24V for 55Vdc, 48V for 110Vdc | ||||
| Charger mode | MPPT | ||||
| PV Low Voltage Re-connect | PV≥Bat.V+3V | ||||
| PV Low Voltage Disconnect | PV<=Bat.V | ||||
| Efficiency | ≥97% | ||||
| AC Charger | Nominal Charger Current | 35A/50A/70A/90A(According to the inverter model) | |||
| Charging Current Settings | 5 stages adjustable charging current | ||||
| Over charge Protection | Bat.V≥15.5VDC for 12V battery, Bat.V≥31.0VDC for 24V battery, Bat.V≥62.0VDC for 48V battery beeps 0.5s every 1s & fault after 60s | ||||
| Efficiency | Efficiency(Battery Mode) | ≥87% | |||
| Efficiency (Line Mode) | >98% | ||||
| Battery Voltage | Nominal DC input Voltage | 12/24/48VDC | |||
| Low Battery Alarm | 10.5VDC±0.3VDC for 12VDC | ||||
| 21VDC±0.6VDC for 24VDC | |||||
| 42VDC±1.2VDC for 48VDC | |||||
| High DC input Alarm & Fault | 16VDC±0.3VDC for 12VDC | ||||
| 32VDC±0.6VDC for 24VDC | |||||
| 64VDC±1.2VDC for 48VDC | |||||
| Transfer Time | 20ms(max) | ||||
| System Parameter | Over-Load Protection | 110%the output,load>150%, beeps 0.5s every 1s, and Fault after 20s | |||
| Output Short Circuit Protection | Current limit (Fault after 10s) | ||||
| Surge Rating(10s) | 1:3(VA) | ||||
| Power Saver | Load≤25W(Enabled on "P/S auto"Setting of Remote control) | ||||
| Protections | Low battery, over charging, over load, over temp | ||||
| General Specifications | Operating Temperature Range | 0ºC~40ºC | |||
| Storage Temperature | -15ºC~60ºC | ||||
| Operation humidity | 5% to 95%(non-condensing) | ||||
| Audible Noise | 60dB max | ||||
| cooling | Forced air,variable speed fan | ||||
| Dimension(L*W*H) | 480*336*190mm | ||||
| Net Weight(kg) | 19.5 | 23.5 | 25.5 | 28 | |
| Product specifications are subject to change without further notice | |||||
