| Model NO. | OLU10048VMII |
| Nature of Source Flow | Active Inverter |
| Output Power | 11kw |
| Power Source | Solar Power |
| Waveform | Pure Sine Wave |
| Charging Method | PV/AC/Generator |
| Peak Efficiency | 94% |
| Origin | China |
A Hybrid Inverter integrates multiple power conversion functions in a single unit for comprehensive energy management solutions. This versatile system combines various power sources and automatically switches between different energy inputs to optimize performance.
The intelligent design provides reliable backup power and reduces energy costs through efficient power management. With automatic switching capabilities and comprehensive energy optimization, these systems deliver enhanced energy savings and reliable operation across diverse applications.
Combines different power sources in a single unit for comprehensive energy management, reducing system complexity while providing a unified control solution.
Incorporates charge controller functionality to optimize energy harvesting from renewable sources, maximizing system efficiency and protecting batteries.
Supports both grid-connected and standalone operation for versatile installation options, providing flexibility for different environments.
| MAIN SPECIFICATIONS | ||
|---|---|---|
| Model | OLU8548VMII | OLU11048VMII |
| Capacity | 8.5KVA/8.5kW | 11KVA/11kW |
| Max. PV Input Power | 10kW | 11kW |
| INPUT & OUTPUT | ||
| Nominal Voltage | 230VAC | |
| Acceptable Voltage Range | 170-280VAC (PC); 90-280VAC (Home) | |
| Surge Power | 17000VA | 22000VA |
| Waveform | Pure Sine wave | |
| BATTERY & CHARGER | ||
| Battery Voltage | 48VDC | |
| Solar Charger Type | MPPT | |
| Max. PV Array Open Circuit Voltage | 500VDC | |
Reduces electricity expenses through intelligent load management and peak shaving capabilities, minimizing grid consumption.
Delivers superior power conversion performance with minimal energy loss, maximizing overall system output.
